Sunon PMD2408PTB1-A 24V DC Cooling Fan, 80x80x25mm, 2-Wire, 60 CFM Ball-Bearing Fan
The Sunon PMD2408PTB1-A is a high-performance 80 x 80 x 25 mm brushless DC axial fan rated at 24 VDC. Its ball-bearing motor spins at 4700 RPM to deliver 60 CFM of airflow, providing strong forced-air cooling for heatsinks and enclosures. It is a popular cooling fan for VFDs/inverters, power supplies, servers and industrial control panels. This model has 2 wire leads (power + / power -).
- 24 VDC rated (10 - 27.6 VDC operating range), 0.21 A
- 60 CFM airflow at 4700 RPM, 107.1 Pa static pressure
- Standard 80 x 80 x 25 mm frame, ball bearing
- 2 wire leads (power only)
- CE, cUR, TUV, UL approved; RoHS compliant
