Barcode:
109-238
HS Code:
85366990
Stäubli PV-KST4-EVO 2A/6I-UR male MC4-Evo 2 Solar Connector — DC 1500 V, 4–6 mm², IP68, genuine MULTILAM contact
The Stäubli PV-KST4-EVO 2A/6I-UR is the male half of the Original MC4-Evo 2 cable coupler — the connector that terminates solar DC cable in a PV array. It suits 4 mm² and 6 mm² conductor with a cable outer diameter of 4.7–6.4 mm and is approved to DC 1500 V under both IEC 62852 and UL 6703, so it works with modern high-voltage string designs. Stäubli's MULTILAM contact system holds contact resistance below 0.2 mΩ for the life of the connector, which is what keeps joints cool and stops the slow power loss and hot-spot risk that cheap connectors introduce. Sealed to IP65/IP68 when mated, UL94-V0, UV and ammonia resistant. Mates with 32.0316P0001-UR and with the wider MC4 family.
• Approved DC 1500 V under both IEC 62852:2014+Amd.1:2020 and UL 6703
• 45 A (4 mm²) / 53 A (6 mm²) IEC; 39 A (12 AWG) / 50 A (10 AWG) UL
• Genuine MULTILAM contact system — contact resistance below 0.2 mΩ
• IP65 / IP68 mated, IP2X unmated; UL94-V0; UV and ammonia resistant
• –40 °C to +85 °C, rated to 5000 m altitude, IEC TS 63126 Level 2
All brand names, trademarks, logos and part numbers are the property of their respective owners and are used for identification and reference only. We are not an authorised distributor or agent of the manufacturer unless expressly stated otherwise.
The Stäubli PV-KST4-EVO 2A/6I-UR is the male half of the Original MC4-Evo 2 cable coupler — the connector that terminates solar DC cable in a PV array. It suits 4 mm² and 6 mm² conductor with a cable outer diameter of 4.7–6.4 mm and is approved to DC 1500 V under both IEC 62852 and UL 6703, so it works with modern high-voltage string designs. Stäubli's MULTILAM contact system holds contact resistance below 0.2 mΩ for the life of the connector, which is what keeps joints cool and stops the slow power loss and hot-spot risk that cheap connectors introduce. Sealed to IP65/IP68 when mated, UL94-V0, UV and ammonia resistant. Mates with 32.0316P0001-UR and with the wider MC4 family.
• Approved DC 1500 V under both IEC 62852:2014+Amd.1:2020 and UL 6703
• 45 A (4 mm²) / 53 A (6 mm²) IEC; 39 A (12 AWG) / 50 A (10 AWG) UL
• Genuine MULTILAM contact system — contact resistance below 0.2 mΩ
• IP65 / IP68 mated, IP2X unmated; UL94-V0; UV and ammonia resistant
• –40 °C to +85 °C, rated to 5000 m altitude, IEC TS 63126 Level 2
All brand names, trademarks, logos and part numbers are the property of their respective owners and are used for identification and reference only. We are not an authorised distributor or agent of the manufacturer unless expressly stated otherwise.
Available from TONUS Group — Industrial MRO & Spare Parts supplier with IT Solutions expertise, serving companies in India, UAE, GCC and Worldwide.
