SSP SAFIX Set I3-A-10M RFID Safety Sensor - PL e / Cat. 4 guard monitoring with a 10 m ready-wired cable
The SAFIX Set I3-A-10M is a non-contact RFID safety sensor for monitoring guard doors, flaps and removable covers on production machinery. The sensor reads an individually coded actuator, giving high level coding to EN ISO 14119 and strong protection against defeat, and its two OSSD outputs connect directly to standard safety relays and safety controllers. Up to 30 sensors can be wired in series without any loss of safety performance, and a three-colour LED plus a separate diagnostic output make fault finding quick. A compact 36 x 13 x 26 mm housing with 22 mm hole spacing, IP69K protection and ECOLAB approval makes it well suited to tight installations, food and beverage lines and washdown areas.
- PL e / Category 4 to EN ISO 13849-1, SIL 3 / SIL CL3 to IEC 62061
- Individually coded actuator (high level coding per EN ISO 14119) for high defeat resistance
- Fast 75 ms response time, 2 x OSSD outputs, up to 30 sensors in series
- IP69K protection with ECOLAB approval and -25 to +70 C operating range
- Supplied with a 10 m fixed cable, open end; 24 V DC supply; three-colour LED diagnostics
All brand names, trademarks, logos and part numbers are the property of their respective owners and are used here for identification and reference only; we are not an authorised distributor or agent of the manufacturer unless expressly stated otherwise.
The SAFIX Set I3-A-10M is a non-contact RFID safety sensor for monitoring guard doors, flaps and removable covers on production machinery. The sensor reads an individually coded actuator, giving high level coding to EN ISO 14119 and strong protection against defeat, and its two OSSD outputs connect directly to standard safety relays and safety controllers. Up to 30 sensors can be wired in series without any loss of safety performance, and a three-colour LED plus a separate diagnostic output make fault finding quick. A compact 36 x 13 x 26 mm housing with 22 mm hole spacing, IP69K protection and ECOLAB approval makes it well suited to tight installations, food and beverage lines and washdown areas.
- PL e / Category 4 to EN ISO 13849-1, SIL 3 / SIL CL3 to IEC 62061
- Individually coded actuator (high level coding per EN ISO 14119) for high defeat resistance
- Fast 75 ms response time, 2 x OSSD outputs, up to 30 sensors in series
- IP69K protection with ECOLAB approval and -25 to +70 C operating range
- Supplied with a 10 m fixed cable, open end; 24 V DC supply; three-colour LED diagnostics
All brand names, trademarks, logos and part numbers are the property of their respective owners and are used here for identification and reference only; we are not an authorised distributor or agent of the manufacturer unless expressly stated otherwise.
